High frequency dynamic generator

Self-developed high frequency dynamic generator, provide both radiography and fluoroscopy working mode;

Highly precise adjustment of exposure parameters (kV, mA and s) for stable and homogeneous radiation emission.

1. Output power: 65.5KW

2. High Working Frequency: 500kHz

3. Maximum Tube Voltage: 40- 150KV(radiography) / 40-125kV(fluoroscopy)

4. Maximum Tube Current:10-800mA(radioraphy)/5-20mA(pulsed fluoroscopy)

Dynamic Flat Panel Detector with High Frame Rate

High resolution images without geometric distortion for precise clinical diagnosis.

1.The large FOV: 427*427mm

2. Pixels: 3072*3072

3. Pixel Size: 139μm

4. Grey Scale:16 bits

5. Highest acquisition speed: 30 frames/second

Automatic electric collimator

Quickly select and preset the desired FOV, saving time in positioning;

One key switches the beam range, efficient and convenient；

Automatically adjust the beam size according to different body position, more intelligent and efficient.

Workstation

One button to turn on/off the machine, simplifying overall workflow, saving preparation time;

Standard DICOM 3.0 interface, supporting film printing, output, storage, barrier-free docking hospital PACS system.

Intelligent image acquisition and processing workstation, with integrating registration, radiography control, image processing and transmission, report printing and other functions.

Humanized menu design to optimize the workflow.

UPS is available for workstation.
